Paper-plastic waste separation and recycling equipment production line
The paper-plastic separator can separate the pulp and plastic on the plastic-coated materials such as milk cartons, wrapping paper, coated paper, paper cups, PP bags, etc. without heating or chemical liquid, and the water can be recycled. , Improve the utilization value. Because of the good separation effect, the separated pulp and plastic are very clean, plastic can be granulated, and paper can be made into pulp, both of which can realize new value. It is the first equipment for making plastic granules and paper pulp.
Paper and plastic separation
Working principle of paper plastic separator:
The working principle of the paper-plastic separator equipment is: the chassis and the rubbing rotor are driven by the transmission shaft to rotate strongly, the slurry moves from top to bottom along the rotor surface, and then is thrown from the lower part of the rotor to the groove wall, and is subjected to the knife again along the groove wall. The high-strength eddy current kneading cycle generated during the powerful movement of the disc makes all kinds of paper and plastic flip up and down in the machine and rotate in the circumferential direction. The continuous friction between the plates fully decomposes the pulp into fibers, and moistens them to avoid cutting and damaging the fibers, and flows out from the pulp outlet under the sieve plate. Impurities such as plastic sheets, backing sheets, and plastic films are less broken (no debris will be formed), and they are discharged from the slag outlet next to the tank, so that the molding and fibers can be completely separated. High pulping efficiency and good separation effect.
Operation and maintenance of paper-plastic separator equipment:
1. Close the slag discharge valve, pour clean water into the tank to 1/3 height, and check whether there is any leakage in the slurry system pipeline.
2. Start the motor, check whether the rotation direction of the impeller is correct, and pay attention to whether the equipment is running normally.
3. When the equipment is operating normally, it can feed materials. Feeding is based on the principle of uniformity, and the concentration is properly controlled.
4. The raw materials containing coarse impurities and metal impurities should be cleaned up to avoid damage to the equipment.
5. Bearings and lubricating oil circuits should be checked frequently, and oil should be refueled less once a month.
Paper-plastic separator maintenance:
Close the slag discharge valve, fill the tank with clean water to 1/3 height, and check whether there is any leakage in the slurry system pipeline. Start the motor, check whether the direction of rotation of the impeller is correct, and pay attention to whether the equipment is running normally. When the equipment is operating normally, it can be fed. Feeding is based on the principle of uniformity, and the concentration is properly controlled.
